General Dynamics C4 Systems URC-200 (V2)
57
Table 12 - Transceiver Customizing Codes
CODE NAME DESCRIPTION
e Transceiver’s
Internal Speaker
The “e” Command followed by the appropriate two decimal digits
sets the state of the transceiver’s internal speaker when transceiver is
turned ON.
“e00” = Speaker is OFF at transceiver turn ON (default)
“e01” = Speaker is ON at transceiver turn ON
Transceiver’s
Front Panel
Backlighting
The “e” Command followed by the appropriate two decimal digits
sets the intensity of the backlighting on the transceiver’s front panel
keyboard and display when transceiver is turned ON.
“e10” = Backlighting OFF (default)
“e11” = Backlighting at intensity level 1 (low)
“e12” = Backlighting at intensity level 2 (medium)
“e13” = Backlighting at intensity level 3 (high)
q Squelch Control
when in the CT
mode
The “q” Command followed by the appropriate three decimal digits
sets the state of the CT squelch.
“q020” = CT squelch is always broken. The Squelch Control has no
effect. (default)
“q021” = CT squelch is broken by the signal level as controlled by
the Squelch Control.
NOTE
1. The Squelch Control can be either the front panel SQUELCH
Control or the remote squelch as controlled by the “$xxx”
command.
2. PT squelch is unaffected by the “qxxx” command.
Scan Control
The “q” Command followed by the appropriate three decimal digits
sets the state of the Scan function.
“q030” = Scanning stops upon completion of a transmission.
(default) “q031” = Scanning resumes upon a completion of a
transmission.
Delay and Timing
Parameters
xx = 00 to 01 yyy = 000 to 255. xx = device number yyy = device
value
Device descriptions:
00: DVI Shutdown Time (Obsolete)
01: PTT Check Squelch Delay
Specifies the amount of time In 10 ms units) to wait before checking
squelch after entering receive mode following a PTT release.
Example:
^01060 sets delay to 600 msecs.
