General Dynamics C4 Systems URC-200 (V2)
56
Table 11 – Remote Transceiver Operation Commands (Continued)
CODE NAME DESCRIPTION
EQUIVALENT
TRANSCEIVER
KEYPAD
COMMAND
B
Transmit
Command
The “B” Command sets the transceiver into
the transmit mode from the receive mode.
NOTE
To set the transceiver back to the receive
mode, use the "E" Command as described
below.
None
E
Receive Mode
The “E” Command returns the transceiver
from the transmit mode back to the receive
mode.
NOTE
To set the transceiver into the transmit
mode, use the "B" Command as described
above.
None
The following command applies to transceivers with the EBN-30 Option, 30-90 MHz Band
Enhancement
>
Note 1
150 Hz Tone
Squelch
This command is only effective for 30 - 90
MHz range frequencies.
Transceivers with the EBN-30 Option, for
the 30-90 MHz band, the “>” Command
followed by a 0, 1, 2, or 3 enables/disables
the 150 tone squelch.
“>0” = Turns OFF the 150 Hz tone squelch
for both receive and transmit.
“>1” = Turns ON the 150 Hz tone squelch
for receive only.
“>2” = Turns ON the 150 Hz tone squelch
for transmit only.
“>3” = Turns ON the 150 Hz tone squelch
for both receive and transmit.
CH/BW
2
TONE
Note 1 – Please see Table 10 (Operational Frequency-Based Dependencies) for restrictions.
