General Dynamics C4 Systems URC-200 (V2)
2
Three options are available. Refer to Paragraph 4.7 for a full description of each option.
• A 30-90 MHz FM Low VHF option.
• An extended 400-420 MHz FM UHF option.
• An 8.33 kHz tuning increment and channel spacing option.
1.2 Features
The features offered by the transceiver include the following:
• Microprocessor controlled transceiver
• COMSEC compatibility. Achieve secure communications with an appropriate
external encryption device and with the transceiver in the data [Cipher Text (CT)]
mode
• Multi-band capability including civilian and military frequencies
• Easy access front panel controls
• Built-in speaker
• RS-232 remote control for all programmable functions
• Backlit display and keypad
• Ten preset memory channels with fully programmable frequencies, including
transmit/receive offsets and AM/FM selection
• Self-calibrating varactor-tuned receiver front-end
1.3 Performance Characteristics
Table 1 identifies the URC-200 (V2) performance characteristics (without 30-90 or 400 MHz
options).
Table 1 - Performance Characteristics
Standard Test Conditions: 28VDC Input, +25 ° C
Characteristics Specifications
General
Frequency Range
VHF - (FM) 115 to 173.995 MHz (AM) 115 to 149.995 MHz.
UHF - (FM) 225 to 399.995 MHz (AM) 225 to 399.995 MHz.
Tuning Increments
25 kHz 12.5 kHz and 5 kHz (8.33 KHz Optional)
Channel Spacing
25 kHz (8.33 KHz Optional)
Stability
±
1 ppm
Preset Channels
10 transmit and 10 receive preset channels.
Modulation
AM or FM
Power
Operating Voltage
+22 to +34 VDC
Current
3.5 Amps Maximum
