General Dynamics C4 Systems URC-200 (V2)
41
4.4.6.7 Select Scan Channels
Pressing the [SCAN] key switches the selected preset channel on or off
the scan list. The scan list must contain from two to ten of the preset
channels before the scan mode can operate. The SCAN annunciator will
light to indicate that this preset channel is on the scan list.
4.4.6.8 Select Transmit Power Levels
FM
LO MED HI
Pressing the [PWR] key selects the transmit power levels for the
transceiver. The power level annunciator will show the current setting.
There are three power levels, LO, MED, and HI, available in the FM
modulation mode and two power levels, LO and HI
selected. This setting will take effect immediately, as indicated by the
annunciator, but will not be saved until the [STO] key is pressed.
4.4.7 Selecting Special Modes
The following paragraphs describe the procedures for special operating modes and functions of the
transceiver. The special operating modes consist of the Beacon-, Guard-, and Scan-mode of
operation. The special functions consist of Internal Voltage Measurements, and Return to Local
Control from Remote operation.
