• 8.33 kHz tuning increment / channel spacing option, ECS-8
Many of the commands are only valid for certain transceiver configurations and frequency ranges,
Table 10 provides mapping of these dependencies. The commands affected by these dependencies
are indicated by a reference to “Note 1” below the command. For example, if the transceiver is
equipped with the 30-90 MHz option and is operating in the 30-90 MHz band, AM is not available,
but FM, PT and CT are, including the other parameters in the remainder of the column. Similarly,
8.33 kHz tuning is available only for the 115 - 173.995 MHz and 225 - 399.995 MHz bands.
Table 10 - URC-200 (V2) Operational Frequency-Based Dependencies
30-90 MHz
1
115 - 173.995 MHz
225 - 399.995 MHz
400-420 MHz
1
AM
N
Y
2
Y
N
FM
Y
Y
Y
Y
PT
Y
Y
Y
Y
CT
Y
Y
Y
Y
Tone Squelch
(150 Hz)
PT only
(unless custom
code used)
N
N
N
25 kHz Tuning
Y Y Y Y
12.5 kHz Tuning
Y
Y
(N in Aviation Mode)
Y
(N in Aviation Mode)
Y
5 kHz Tuning
N
Y
(N in Aviation Mode)
Y
(N in Aviation Mode)
Y
8.33 kHz Tuning
1
N
Y
Y
N
Selectable IF
Filter
1,3
(AM PT)
N
Normal mode: Y
Aviation: N (Auto)
4
N
N
Pre/De-Emphasis
(FM PT)
N
Y
(132-173.995 MHz)
N
Y
FM RF Output
Power
5W, 1W, or 0.15W
10W, 5W, or 0.1W
10W, 5W, or 0.1W
10W, 5W, or 0.1W
AM RF Output
Power
NA
10W or 5W
10W or 5W
NA
1 Indicates an option.
2 Transceiver operates over full band, but spec is guaranteed from 115 - 149.995 MHz only.
3 The 8.33 kHz filter only applies to 117.975 – 136.975 MHz.
4 (Auto). Indicates that as you enter the frequency, an 8.33 or 25 kHz channel is selected and the correct filter is
automatically selected, depending on the value entered.
Refer to Paragraph 4.7 of this manual for more information about available options.
