Zoom | 116Applications
9.4 Reference Element - Reference Arc
9.4.1 Overview
Description The Reference Element - Arc application allows the user to define a reference
arc and then complete the following tasks with respect to the arc:
• Line & offset
• Set out (Point, Arc, Chord, Angle)
Access 1) Select Apps from the MAIN MENU.
2) Select Reference Element from the APPS menu.
3) Complete application pre-settings. Refer to "8 Applications - Getting
Started".
4) Select Arc.
Next step Define the reference arc.
