9.11.3 As Built Check
Description The As built screen displays the Line, Offset and d.d.Z of a measured point in
relation to the construction line. The on-screen graphics show the position of
the measured point relative to the construction line.
)
The height of the line start point is always used as the reference height!
Access Press AsBLT from the LAY OUT screen.
AS-BUILT CHECK The graphics are scaled to give a better overview. Therefore it is possible that
the station point moves in the graphics.
LAYOUT
To switch to Layout mode to set
out points.
Shift
To enter values for shifting the
line.
