Applications Zoom | 119
9.4.3 Subapplication Measure Line & Offset
Description The Measure Line & Offset subapplication calculates from measurements or
coordinates, longitudinal and orthogonal offsets and height differences of the
target point relative to the reference arc.
Access Press MEAS from the REFERENCE ARC screen.
Measure
Next step • Either, press ALL to measure and record.
• Or, press BACK to return to the REFERENCE ARC screen.
Field Description
dLine Calculated distance longitudinal to the reference arc.
dOffset Calculated distance perpendicular from the reference arc.
d.d.Z Calculated height difference relative to the start point of refer-
ence arc.
To Next Page
