Zoom | 224Technical Data
Accuracy Accuracy refers to measurements to standard reflectors.
Beam interruptions, severe heat shimmer and moving objects within the beam
path can result in deviations of the specified accuracy.
Characteristics
EDM measuring mode Standard deviation
ISO 17123-4
Measurement
time, typical [s]
IR-Default 2 mm + 2 ppm 2.4
IR-Quick 5mm + 2ppm 0.8
IR-Continuous 5 mm + 2 ppm <0.15
Foil 5 mm + 2 ppm 2.4
Principle: Phase measurement
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: System analyser basis 100 MHz - 150 MHz
