Zoom | 226Technical Data
A6 (without reflector)
Atmospheric
conditions
Accuracy
Beam interruptions, severe heat shimmer and moving objects within the beam
path can result in deviations of the specified accuracy.
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 % reflective 350 1150 450 1480 ≤600 ≤1970
Grey side, 18 % reflective 200 660 250 820 ≤350 ≤1150
Range of Measurement: 1.5 m to 1200 m
Display unambiguous: up to 1200 m
Range D: Object in strong sunlight, severe heat shimmer
Range E: Object in share, or overcast
Range F: Day, night and twilight
Standard
measuring
ISO 17123-4 Measure time,
typical [s]
Measure time,
maximum [s]
0m - 500m 3mm + 2ppm 3 - 6 12
>500 m 4 mm + 2 ppm 3 - 6 12
