Packaging
3–6 INS 61301607027 Rev A US
2. Using the pallet jack, raise the sterilizer skid until the outer beams can
be removed (see Figure 3–4).
FIGURE 3–4. REMOVING THE OUTER BEAMS
CAUTION
DAMAGE TO EQUIPMENT: Do not extend the leveling bolts more than 5
inches (127 mm). The bolts are 6 inches long (152 mm) and might be
damaged by the weight of the sterilizer if overextended.
3. Once the outer beams have been removed, turn down all four leveling
feet until they extend below the skid.
4. Lower the sterilizer skid until the leveling feet rest on the floor.
5. Remove the pallet jack.
A07027-BH
Outer Beam
Pallet Jack
Forks
Turn down leveling feet
(4 places) while unit is
lifted by pallet jack
To Next Page
