Insert the thinner part of the pulling rod with handle into the thicker one,
lock the position using aluminum metal pin and screw the black plastic nut using
slight force.
Connect the pulling rod with the sledge. Assemble the joint according to the
following picture. Put the hollow metal plug with two black rings into the hole then
insert the aluminum pin (from bottom to top) and fix it by aluminum ring with split
key.
Now the probe is ready to use. The connection between the probe and the
control unit is provided via Bluetooth communication. The Bluetooth adapter (with
Power switch) is placed under the small cover of the sledge. See the chapter Using
Bluetooth adapter for remote control.
