GF EA25 - DIN-plug connection

19
Instruction manual
Electric Actuators Type EA15-250
3.7.3 Connection type DIN-plug
Connection type DIN-plug
Power supply
Position feedback
3
3
2
1
OPEN
V+
CLOSE
V+
N
PE
3
3
2
1
OPENCLOSE
N
N.C.
