ProfiLux 4 Programming Guide
EN 2017-02-06 29
3.12 Variable Illumination
This function allows you to use different illumination runs for a luminaire on different
weekdays.
Up to 16 variable lighting programs can be defined. After selecting the program (1 to 16), you
can set for Monday to Sunday, which lighting sequence (1 to 16, Illumination run) should be
used on the respective day.
3.13 Mitras Lightbar
Activate this setting when you have connected our Highpower LED Illumination Mitras®
Lightbar. You can also specify which of the available serial interfaces (usually COM1) are to be
used to control the Mitras Lightbar.
Here you can change the output power of the Mitras Lightbar.
3.14 Light demo
The Lightdemo serves for demonstration purposes. After activation, the LEDs are alternately
dimmed up and down.
With the keyboard the Lightdemo can be varied:
Arrow up and down – Color change faster or slower
Arrows left and right - Change the color pattern
Return - Freeze the current color pattern, press Return again restarts the automatic
sequence
You would like to have for the illumination from Monday to Friday other
settings than for Saturday and Sunday, so you need 2 different illumination
runs.
First you set both illumination runs (e.g. illumination run 1 for Monday to
Friday and illumination run 5 for Saturday and Sunday) according to your
wishes.
Afterwards you set e.g. Variable Illumination 1 accordingly (Monday: 1,
Tuesday: 1, …, Friday: 1 and Saturday: 5 and Sunday: 5).
Finally you choose the function Variable Illumination 1 as function for the
corresponding 1-10 V-interface (see also System ->1-10 V interface) resp. for
the corresponding switchable socket (see also System ->Socket outlet
function.
