GHL ProfiLux 4 Programming Guide

ProfiLux 4 Programming Guide
EN 2017-02-06 46
Sensor type
Minimum
Maximum
Standard
Resolution
pH
0.05
1.00
0.30
0.01
Temperature
0.15 °C
2.00 °C
0.20 °C
0.01 °C
Redox
10 mV
100 mV
20 mV
1 mV
Conductivity freshwater
8 µS
200 µS
20 µS
1 µS
Conductivity salt water
0.3 mS
10.0 mS
0.5 mS
0.1 mS
Oxygen
2.0 %
10.0 %
5.0 %
0.1 %
Humidity
0.2 %
15.0 %
2.0 %
0.1 %
Air temperature
0.2 °C
3.0 °C
0.5 °C
0.1 °C
Voltage
0.05 V
3.00 V
0.50 V
0.01 V
5.5 Alarm
ProfiLux 4 can monitor the currently measured value of a sensor and react in various ways in
the event of an excessive deviation.
Please first set whether the alarm should be active. If you selected Yes, please proceed as
follows:
 Determine the Maximum deviation of the actual value from the nominal value.
 Select whether you want to disable this control in the event of an alarm (Shut-off
control?).
Note for temperature sensors
The adjusted hysteresis also depends on when the cooling is active. The
switching-on point of the cooling also depends on the cooling difference
(see also Sensors-> Cooling difference) and can be calculated as follows:
T = nominal temperature + 5/6 * hysteresis + cooling difference
With a hysteresis of 0.2 °C, this results: T = Nominal temperature + 0.167 °C
+ cooling difference.

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
