ProfiLux 4 Programming Guide
EN 2017-02-06 52
5.9.3 Overview of the Calibration values
(If the minimum and maximum are the same, then the calibration value cannot be changed)
5.9.4 Temperature Sensor (Analog)
This applies exclusively to external analog temperature sensor inputs (for example, from PLM
Temp)
The already installed sensor input for the digital temperature sensor of the ProfiLux 4
can and must not be calibrated.
Additional external analog temperature sensor inputs (for example, of additional expansion
cards PLM-Temp) must be calibrated!
Each ProfiLux Expansion Card with temperature sensor input is accompanied by a calibration
document.
Please enter the two values listed under Calibration ADC1 and Calibration ADC2 during
calibration. After entering these two values, the temperature sensor input is calibrated.
Sensor type
Calibration
possible
Calibration
values
adjustable
Min.
calibration
value 1
Max.
calibration
value 1
Min.
calibration
value 2
Max.
calibration
value 2
pH
yes
Yes
3.5
7.5
5.5
10.0
Temperature
yes
No
20.0 °C
20.0 °C
30.0 °C
30.0 °C
Redox
yes
Yes
0.0 mV
0.0 mV
200 mV
250 mV
Conductivity
saltwater
yes
Yes
0 µS
0 µS
1000 µS
2000 µS
Conductivity
freshwater
yes
Yes
0.0 mS
0.0 mS
40.0 mS
80.0 mS
Oxygen
yes
No
0.0 %
0.0 %
10.0 %
102.0 %
Humidity
no
No
0.0 %
0.0 %
100.0 %
100 %
Air temperature
no
no
0.0 °C
0.0 °C
100.0 °C
100.0 °C
Voltage
no
no
0.0 V
0.0 V
10.0 V
10.0 V

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
