ProfiLux 4 Programming Guide

EN 2017-02-06 31

Then the lighting channels are operated with 50% of the normally set brightness on the

01.12.2016 (and also before), on the second day with 75%, and on the last day with 100%

(and also thereafter).

Starting and ending percentages can be adjusted as needed; thus an increase as well as a

lowering over a certain period of time is possible..

3.17 Shift Curves

This function allows you to move complete illumination runs.

 Select the illumination(s) whose illumination run(s) you want to move.

 Then determine the time offset and confirm with ->RETURN

4 Extras

Special functions and settings are summarized here. The following submenus are provided.

4.1 Maintenance

During the maintenance and care of the aquarium, it can be helpful to set the switch state of

some switch sockets or the brightness of luminaires explicitly.

An example would be switching the heaters off, setting the flow to minimum and setting a

dimmable lightbar to 80%.

Note

In order to achieve maximum flexibility, the settings of the maintenance

function refer directly to the hardware (switch sockets and 1-10 V interfaces)

...

...and not on control and regulation functions (e.g., temperature control or

illumination channels).

ProfiLux 4 offers 4 separately adjustable Maintenance programs.

In the Maintenance menu, you can set the maintenance parameters under Settings. For quick

access, the maintenance programs are positioned on top, one after the other. The menu

item Settings will show up afterwards. Scroll down the menu until you reach Settings. Then

select the Maintenance program you want to edit.

Set affected 1-10V interfaces
