ProfiLux 4 Programming Guide

EN 2017-02-06 59

Based on your execution, ProfiLux 4 displays now the correct (compensated) temperature

value.

5.13 Measurement Range

For some measuring inputs for sensors, it may be necessary to first set the Measuring range

before calibration.

 Select the respective sensor under Sensor settings and confirm with RETURN.

 ProfiLux 4 offers you the possible measuring ranges for selection

Temperature

Here the measuring range can be selected for the connected temperature sensor. There are

2 types of water temperature sensors:

Aquarium – Measuring range approx. 11.5 °C (52.7°F) to 38 °C (100,4°F)

Pond - Measuring range approx. 0 °C (32°F) to 40 °C (104°F)

At default, the measuring range is set for the aquarium. Change the measuring range when

you connect a pond sensor! If the measuring range and sensor used do not match, incorrect

temperatures are measured!

Conductivity

If the relevant input is an onboard input of ProfiLux 4, the measuring range can be changed

here - for seawater or freshwater. Please note that when the measuring range is changed, all

settings for this input are lost and set to the factory setting.

5.14 Density Offset

(Only with conductivity sensor saltwater)

For the density display of seawater, an offset between -0.005 and +0.005 can be set here if

the displayed density value deviates from the actual value.

5.15 1-10 V max. at…

(Only with temperature sensor)

This setting allows you to define at which temperature the assigned 1-10 V interface (for

example, for PTC or PropellerBreeze) should have the maximum output voltage.

The connected device then has the maximum power with this temperature deviation.

Adjustable are values between 0.2 °C und 10 °C.
