GHL ProfiLux 4 Programming Guide

ProfiLux 4 Programming Guide
EN 2017-02-06 44
Conductivity fresh water
10 µS
1900 µS
500 µS
1 µS
Conductivity salt water
0.5 mS
99.5 mS
50.0 mS
0.1 mS
Oxygen
0.0 %
130.0 %
100.0 %
0.1 %
Humidity
2.0 %
98.0 %
60.0 %
0.1 %
Air temperature
0.0 °C
50.0 °C
28.0 °C
0.1 °C
Voltage
0.00 V
10.00 V
5.00 V
0.01 V
WARNING
For safety reasons, a possibly set nocturnal change (own menu item
nocturnal change) is deactivated during the processing of the nominal
value!
If you need to make a nocturnal change, you must reactivate it after the
nominal value processing.
Note
Please note the following in the temperature control:
The heat radiation of the lighting and the outside temperature can affect
the water temperature. If there is no cooling, it is possible that the set-point
temperature is exceeded.
Depending on the difference between the desired and the current
temperature, the heaters or the cooling are switched. The following states
can occur:
Tubular heater and substrate heating on / Only substrate heating on / All off
/ Cooling only
ProfiLux 4 is programmed in such a way that the substrate heating takes
precedence over the tubular heater. This makes an optimal heating of the
substrate possible. The tubular heater is then switched on when the
substrate heater alone is no longer sufficient.

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
