58452 VXIbus Universal Power Meter
5-6 Publication 21555, Rev. E, September 2002
DIAGnostic:GAINspaceA-B,0-1,-2-3-4-5-6,N-I-G-O
OUTPUT @PWR_MTR;DIAG:GAIN
Set gain circuit; Channel, Gain, Mode, A,B
Channel, Gain 0 to 6; N: Non_invert, I: Invert,
G:Ground, O:Option
DIAGnostic:LEDspaceON-OFF
OUTPUT @PWR_MTR;DIAG:LED ON
Turn trigger led on
DIAGnostic:MULtiplexerspaceMA-MB-MC .... MO-MP
OUTPUT @PWR_MTR;DIAG:MUL MA
Set multiplexer
DIAGnostic:MEASurementspaceSTARt-STOP
OUTPUT @PWR_MTR;DIAGMEAS STAR
Resume measurement process
DIAGnostic:OFFSetspace3.5
OUTPUT @PWR_MTR;DIAG:OFFS 3.5
Set ADC offset to 3.5V (-5 to +5)
DIAGnostic:RAM?
OUTPUT @PWR_MTR;DIAG:RAM?
Query ram destructive test result (0 = Pass;
1 = Fail)
DIAGnostic:ROM?
OUTPUT @PWR_MTR;DIAG:ROM?
Query rom test result (0 = Pass; 1 = Fail)
DIAGnostic:RAWdataspace<ON or OFF>
OUTPUT @PWR_MTR;DIAG:RAW ON
Enable measurement raw data output
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:READ
OUTPUT @PWR_MTR;DIAG:SENS1:READ
Read eeprom table data from sensor 1 into
editor memory
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:WRITe 123456
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:WRIT 123456
Write eeprom sensor 1 editor data into sensor
(Using password)
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:TYPE
80301,0,59,9,22,12,92,0
OUTPUT @PWR_MTR;DIAG:SENS2:TYPE 80301,0,59,9,22,12,92,0
Edit sensor 2 eeprom type table data: model,
s/n, cal location, min, hour, day, month, year,
password flag (0:Disable, 1:Enable)
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:SPEC 1e7,18e9,4100,3900
OUTPUT @PWR_MTR;DIAG:SENS2:SPEC 1E7,18E9,4100,3900
Lower frequency, upper frequency video R+, R-
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:TYPE?
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:TYPE?
Query sensor 1 eeprom type table data
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:CORRection
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:CORR “1.1,2.1,3.1,4.1,5.1,6.1,7”
Edit sensor 1 eeprom correction table:
A,B,C,D,E,H
DIAGnostic:SENS<sensor 1 or 2>:EEPROM CORRection?
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:CORR?
Query sensor 1 eeprom correction table
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:CALFRange 2e9,1e9,17,1
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:CALFR 2E9,1E9,17,1
Edit sensor 1 eeprom cal factor range
table:standard:start:cf freq, step cf freq, cf
number, special cf number
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:CALFRange?
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:CALFR?
Query sensor 1 eeprom cal factor range table
DIAGnostic:SENS<sensor 1 or 2>:EEPROM:FREQSTandard?
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:FREQST?
Query sensor 1 eeprom cal factor standard freq
table
DIAGnostic:SENS<sensor 1 or 2>:FREQSPecial?
OUTPUT @PWR_MTR;DIAG:SENS1:EEPROM:FREQSP?
Query sensor 1 eeprom cal factor special freq
table
Table 5-1: Diagnostic Commands (Continued)
Command Syntax Function
