Operation
Publication 21555, Rev. E, September 2002 2-15
MEMory[:TABLe]:POWerspace<start value from 0 to
0.01W>comma<stop value from 0 to 0.01W>
Set analog out power range (in Watts) from
0 to 0.01 Watts
2-47
MEMory[:TABLe]:SELectspace<ANALOGout,VPROPF1,
VPROPF2>
Select memory table V
PROP
F1 for editing in
following lines
2-27
2-47
MEMory[:TABLe]:SLOPespace<Volts per Hz>
Set V
PROP
F slope in 1V/GHz 2-27
MEMory[:TABLe]:UNITspace<Units for analog output configuration,
dBm or Watt>
Set analog out power unit 2-47
MEMory[:TABLe]:VOLTagespace<start value from -10 to +10
V>comma<stop value from -10 to +10 V>
Set analog out voltage range from -8 to 2
volts corresponding to power
2-47
OUTPut[:BNC]:ANAlog[:STATe]space<ON | OFF>
Enable analog out function
OUTPut:ROSCillator[:STATe]space<ON | OFF>
Turn ON 0.0 dBm Calibrator Oscillator 2-53
READ<channel 1 to 2>[:POWer]?
Trigger measurement and read channel 2 2-19
SENSe<sensor 1 or 2>:AVERage:COUNtspace<averaging value
1,2,4,8,16,32,64,128,256,or512>
Set sensor 1 average number to 16
2-36
SENSe<sensor 1 or 2>:AVERage:COUNt:AUTOspace<ON | OFF>
Select sensor 2 Auto-average mode
SENSe<sensor 1 or 2>:AVERage:TCONtrolspace<data acquisition
averaging method, MOVing or REPeat>
Set sensor 1 to acquire fresh measurement
data before averaging
SENSe<sensor 1 or 2>:CORRection:EEPROM:TYPE?
Query sensor 1 eeprom type
2-53
SENSe<sensor 1 or 2>:CORRection:EEPROM:FREQuency?
Query sensor 1 eeprom frequency table
SENSe<sensor 1 or 2>:CORRection:EEPROM:CALFactor?
Query sensor 1 eeprom cal factor table
SENSe<sensor 1 or 2>:CORRection:FREQuency[:CW-FIXed] 5e7
Set sensor 2 frequency to 50 MHz 2-27
SENSe<sensor 1 or 2>:CORRection:OFFSet:COLLect
Take sensor 1 current reading as offset
value
2-38
SENSe<sensor 1 or 2>:CORRection:OFFSet
[:MAGnitude]space<offset value in dB -99.99 to 99.99>
Compensate sensor 2 for 10.2 dB
attenuation
SENSe<sensor 1 or 2>:CORRection:OFFSet:STATespace<ON |
OFF>
Enable sensor 2 offset correction
SENSe<sensor 1 or 2>:CORRection:VPROpf[:STATe]space<ON |
OFF>
Enable sensor 1 v_prop_f function 2-27
SENSe<sensor 1 or 2>:TEMPerature?
Query sensor 1 temperature (in centigrade) 2-18
SENSe<sensor 1 or 2>:TRIGger:SOURcespace<peak sensor
triggering INTernal, EXTernal or CW>
Set sensor 1 peak trigger mode to CW
mode
2-34
SENSe<sensor 1 or2>:TRIGger:DELay[:MAGnitude]:space<Peak
Sensor sample delay in seconds from -20e-9 to 104e-3>
Set sensor 2 peak delay value to 1e6
seconds
SENSe<sensor 1 or 2>:TRIGger:DELay:STATespace<ON | OFF>
Enable peak sensor 1 delay function
Table 2-2: VXI GPIB Command Syntax (Continued)
Command Syntax Function Page
