58542 VXIbus Universal Power Meter
2-16 Publication 21555, Rev. E, September 2002
SENSe<sensor 1or2>:TRIGger:LEVel[:MAGnitude]space<trigger
level of peak power sensor>
Set peak sensor 1 trigger level to 1.7 volts
2-35
SENSe<sensor 1 or 2>:TRIGger:OFFSet[:MAGnitude]
Set peak sensor 1 trigger offset time to 0
second
SENSe<sensor 1 or 2>:TRIGger:TOTAl[:MAGnitude]?
Query peak sensor 1 total trigger delay
time
STATus:OPERation[:EVENt]?
Query operation event register result
2-40
STATus:OPERation[:ENABle]
Set Status Enable Mask
STATus:PRESet
Clears all the status register value 2-40
2-50
SYSTem:ERRor?
Query system error message 2-59
SYSTem:PRESet
Reset 58542 configuration 2-50
SYSTem:VERSion?
Query SCPI version 2-52
TRIGger[:IMMediate]
Trigger measurement cycle
2-22
TRIGger:SOURcespace<instrument triggering source
IMMediateBUS, HOLD, or EXTernal>
Set instrument measurement trigger
source to IMMediate
TRIGger:MODEspace<burst mode data gathering POST trigger
receipt or PRE trigger receipt>
Set Burst or Swift mode data collection
relative to Timing of event trigger post
2-21
TRIGger:DELayspace<delay time between buffered readings in sec
0.000 to 5.000>
Set Burst mode measurement time to 5 ms
between measurements (resolution, one
msec)
2-23
TRIGger:COUNtspace<number of data values to buffer in memory
from 1 to 5000 for standard 58542 from1 to 128,000 on one channel
with option 02; from 1 to 64000 for two channels with option 02>
Set Burst or Swift mode buffer reading
number to 100
Table 2-2: VXI GPIB Command Syntax (Continued)
Command Syntax Function Page
