58542 VXIbus Universal Power Meter
2-56 Publication 21555, Rev. E, September 2002
400 0 0 50 CALIBRATOR DAC
This test steps the calibrator control DAC from 0
to 10volts in 1 volt steps and measures the
resultant output voltage with the system ADC. It
then compares the results with the limits shown to
the left and if outside any limit it will set the error
number corresponding to that voltage level.
401 1000 950 1050
402 2000 1900 2100
403 3000 2850 3150
404 4000 3800 4200
405 5000 4750 5250
406 6000 5700 6300
407 7000 6650 7350
408 8000 7600 8400
409 9000 8550 9450
410 10000 9500 10500
600 0 50 50 OFFSET AMP 1
This test steps the sensor input amplifier offset
DAC from 0 to 5volts in 1volt steps and
measures the resultant output voltage from the
first amplifier stage with the system ADC. It then
compares the results with the limits shown to the
left and if outside any limit it will set the error
number corresponding to that voltage level.
601 1000 950 1050
602 2000 1900 2100
603 3000 2850 3150
604 4000 3800 4200
605 5000 4750 5250
800 0 0 50 GAIN AMP 2
This test steps the sensor input amplifier offset
DAC from 0volts to 5volts in 1volt steps, sets
the second stage gain to 1 and measures the
second stage output voltage with the system
ADC. It then compares the results with the limits
shown to the left and if outside any limit it will set
the error number corresponding to that voltage
level.
801 1000 950 1050
802 2000 1900 2100
803 3000 2850 3150
804 4000 3800 4200
805 5000 4750 5250
1000 0 0 50 THRU FILTER
This test steps the sensor input amplifier offset
DAC from 0 to 5volts in 1volt steps, and
measures the filter amplifier output voltage with
the system ADC. It then compares the results with
the limits shown to the left and if outside any limit
it will set the error number corresponding to the
voltage level.
1001 1000 950 1050
1002 2000 1900 2100
1003 3000 2850 3150
1004 4000 3800 4200
1005 5000 4750 5250
Table 2-5: Self-Test Error Indication & Limitations (Continued)
