58542 VXIbus Universal Power Meter
2-58 Publication 21555, Rev. E, September 2002
2101 5000 4500 5500 SW +5 ON
This test measures the switched 5volt logic
supply applied to the sensor when it is switched
on. Whenever a peak power sensor (8034X or
8035XA) is connected, this test will be bypassed.
3000 0x3c0000 0x3FFFFF RAM BANK 1
This does a byte by byte check of the optional
extra 128K RAM at addresses 3c0000 to 3fffff
hex. An error at any address will result in an error
number of 3000. If the optional RAM is not
present (which is tested by checking the first byte
for write/read cycle ability), then this test is
aborted without an error flag.
3001 0x400000 0x43FFFF RAM BANK 2
This does a byte by byte check of the standard
RAM at addresses 400000 to 43ffff hex. This is
done in a non-destructive manner by saving the
data that is present and then writing a pattern,
reading it back, checking it for validity, and then
restoring the original. An error at any address will
result in an error number of 3001.
3100 0x300000 0x37FFFF ROM
This does a complete checksum of the program
ROM at addresses 300000 to 37ffff hex and
compares it with the correct value stored in the
ROM. Any error will result in an error number of
3100.
Table 2-5: Self-Test Error Indication & Limitations (Continued)
Error Number Result Minimum Maximum Test Description
