Detail program description - Joystick setting | Winged models
global
Channel 1
Aileron
Elevator
Rudder
Tr im
0.0s
Tr. step – time +
global
0.0s
Phase
0.0s
global
0.0s
0.0s
0.0s
0.0s
0.0s
4
4
4
4
Briefl y tap the center SET key of the right touch pad.
The current setting will be displayed in inverse video.
Now select the desired value, between 1 and 10,
with the selection keys of the right touch pad. For
example:
global
Channel 1
Aileron
Elevator
Rudder
Tr im
0.0s
Tr. step – time +
global
0.0s
Phase
0.0s
global
0.0s
0.0s
0.0s
0.0s
0.0s
4
4
8
4
A simultaneous tap on the cd or ef keys of the
right touch pad (CLEAR) will reset any change made
to the active fi eld back to "4".
Time
The rate of control signal change with respect to the
speed of joystick motion can be infl uenced by the
entries made in the "– time +" column. Each joystick
movement direction, i.e. joystick control channels
1 through 4, can be set individually. This means
that respective servos will then follow rapid control
position changes only at an accordingly delayed
rate. This time delay has a direct effect on the control
function and therefore also any servos controlled by
this function.
The time can be programmed symmetrically for both
sides or separate for each control direction. This
setting has a programmable range of 0 s to 9.9 s. In
the case of side-separate settings, the joystick is to
be moved to the respective side so that the inverse
video fi eld will switch between sides to the one for
which the change is to be made – for example, even
to ensure gentle rev-up of the propulsion motor
despite a (too) fast motion of the C1 stick.
global
Channel 1
Aileron
Elevator
Rudder
Tr im
1.1s
Tr. step – time +
global
0.0s
Phase
0.0s
global
0.0s
0.0s
0.0s
0.0s
0.0s
4
4
8
4
On the other hand, for reasons of safety, the motor
cut-off should always be "immediate".
A simultaneous tap on the cd or ef keys of the
right touch pad (CLEAR) will reset any change made
to the active fi eld back to "0.0 s".
