GRAUPNER MC-20 HoTT User Manual

11
Remote control set description
metsySretupmoC mc-20
-zHG4.2niteslortnocetomerlennahc23 Graupner-HoTT technology
(Hopping Telemetry Transmission)
Technology that enthralls
The superior functional security of Graupner
HoTTTechnology accomplished with bidirectional
communications between transmitter and
receiver with integrated telemetry, freely
programmable voice output via headset
connector, and ultra-fast response times.
PrQITCOOKPIKUUKORNKſed by a programming
technique implemented with capacitive touch
buttons.
High contrast, 8 line, graphic display for perfect
presentation of all parameter settings. Switch
on/off of blue back-lighting at will. A second,
independent display for presentation of telemetry
data. Storage of telemetry data on a micro
SD memory card.
4096 steps of 12-bit resolution on the channel
signal assures extreme control sensitivity.
USB connection to read and write the model's
memories as well as fQTOCMKPIſrmware updates
Integrated• Graupner HoTT 2.4 GHz transmission
system
Maximum interference immunity made possible b •
optimized frequency hopping through as many as
75 channels and wider channel spread
Intelligent data transfer with correction function•
Over 200 systems can be used simultaneously•
The HoTT technique of bidirectional •
communication between sender and receiver,
as well as the fastest possible transmission rate
(10 ms) assures extremely short reaction times.
5 different languages (German, English, French,•
Italian and Spanish) available per software
update. For the availability of a given language,
refer to the download area.
80 model memories with storage for all model-•
speciſc programs and parameter settings
Seven switches (two 3-way switches, three 2-way•
switches and two 2 pushbutton switches) as well
as three digital actuators are already built-in and
can be used as desired
A function encoder with two touch-sensitive,•
four-way keys ("CAP Touch") permit simpliſed
programming and precise settings
Key-lock function to prevent unintentional•
operation.
Voice and, as applicable also MP3 ſle, output over•
headset output or loudspeaker
Simple, very fast model-independent binding•
Extremely fast rebinding, even at maximum•
distance
Range: test and warning function•
Under-voltage warning•
Extremely wide receiver operating voltage range•
of 3.6 V to 8.4 V (functional to 2.5 V)
Fail-safe, free channel assignment (channel •
mapping), mixer functions and all servo settings
are simple to program
