Profi trim
Pitch, throttle, tail-rotor, and C1 curve trimming
The mc-20 HoTT transmitter's software has an
integrated function for additional trimming of 8-point
curves; in Heli programs »Channel 1 curve« page
131, and »Helicopter mixer« page 176. These are
intended for "Pitch" curves "Channel 1 ¼ Throttle"
and "Channel 1 ¼ Tail. rot.".
This feature, named »Profi trimm« because of its
functional similarity to the Profi -Trim module for the
mc-24 but only available on that transmitter as a
retrofi t option. Select this feature from the multi-
function menu with the selection keys of the left or
right touch pad …
Fl. phase timers
Helicopter mixer
Free mixer
MIX active/phase
MIX-only channel Dual mixer
Swashplate mixer Fail-safe adjust
Teacher / pupil Tx. output swap
Profi trim
Trim memory
… then open this menu option with a brief tap on the
center
SET key of the right touch pad.
Mixer
Point Phase
free
free
free
free
None
None
None
None
L1
1
1
1
L
L
L
"Trim control" column
Note:
Pay attention to potential double-assignments when
making trim control choices.
This menu's fi rst line is for assigning those transmitter
controls (from the many available on the transmitter)
which appear most advantageous for this purpose.
To assign a transmitter control, use the selection keys
to navigate to the desired line then tap briefl y on the
center
SET key of the right touch pad …
Mixer
Point Phase
free
free
free
free
None
keiner
keiner
None
L1
1
1
1
L
L
L
Move desired
control adj.
… then move the desired transmitter control:
Mixer
Point Phase
Slide1
free
free
free
None
None
None
None
L1
1
1
1
L
L
L
Erase trim control
Select the transmitter control assignment in the
appropriate line as already described, e.g.:
Mixer
Point Phase
Slide1
free
free
free
None
keiner
keiner
None
L1
1
1
1
L
L
L
Move desired
control adj.
A tap, at the same time, on the cd or ef selection
keys of the right touch pad (CLEAR) will now reset
the fi eld's value back to "free".
"Mixer" column
There are a total of four value fi elds in this column. For
each of these fi elds a helicopter mixer can be selected,
individually or in any combination, from a list.
To do this, use the selection keys on the left or right
touch pad to change to the desired value fi eld. Then
briefl y tap the center
SET key of the right touch pad …
Mixer
Point Phase
Slide1
free
free
free
None
None
None
L1
1
1
1
None
L
L
L
… and select the desired mixer with the selection
keys of the left or right touch pad:
Mixer
Point Phase
Slide1
free
free
free
None
None
None
L1
1
1
1
Pitch
L
L
L
Another tap on the center SET key of the right touch
pad or the
ESC key of the left touch pad will conclude
the entry. This procedure is the same for the other
menus.
A tap, at the same time, on the cd or ef selection
keys of the right touch pad (CLEAR) will reset a fi eld
displayed in inverse video back to "None".
