221
Detail program description - Profi -trim | Winged models
Control
PRO TRIM
AI
AI
FL
FL
Tr im
act
act
off off
ctl sw free
on/off
SET
SET
SET
SET
free
free free
The second line of this menu is for selecting
transmitter control assignments which appear
advantageous from the many controls available on
the transmitter.
To assign a transmitter control, use the selection keys
to navigate to the desired column then tap briefl y on
the center
SET key of the right touch pad …:
PRO TRIM
QR
AI
FL
WK
Tr im
actN
AUS
AUS off
ctl sw Lever1
on/off
SET
SET
SET
SET
free
free free
Move desired
control adj.
… and move the desired transmitter control:
PRO TRIM
AI
AI
FL
FL
Tr im
act
act
off off
ctl sw Tvr1
on/off
SET
SET
SET
SET
Tvr2
free free
The mid-point position of enabled proportional
controls corresponds to the programmed fl ap setting.
The trim range for a given transmitter control is
about ±25 %. However, these "trim" controls are
only effective when, as described in section "ON/
OFF" further below, has been assigned to a profi -trim
switch and switched on.
With trims switched on, make a test fl ight to
determine the optimal setting then open the ON/
OFF switch to secure the setting against inadvertent
maladjustment. Now as long as the ON/OFF switch
remains open or is erased, the located trim values will
retain their settings.
An active transmitter control assignment can be
erased with a simultaneous tap on the cd or ef
selection keys of the right touch pad (CLEAR).
Note:
Trim values retain their settings until the next closure
of the ON/OFF switch, even then when the trim
functions in the "Control" line have been temporally
reset to "free".
ON/OFF
The "ON/OFF" line is used to assign a switch which
permits the profi -trim function to be switched on/
off globally. This assignment is done in the manner
described in the section "Assigning transmitter
controls, switches and control switches" on page 56.
In this context, pay attention to the following
dependencies:
Only when the ON/OFF switch in the "Trim" line is
set to "ON" will the trim functions assigned to trim
controls in the "Transm. controls" line be able to
affect trim within a range of ±25 %.
As soon as the ON/OFF switch is opened or
erased, the current trim positions will be stored
and the selected trim controls become ineffective.
A tap, at the same time, on the cd or ef selection
keys of the right touch pad (CLEAR) when a switch
assignment is active will reset a fi eld's value back to
"---":
PRO TRIM
AI
AI
FL
FL
Tr im
act
act
off off
ctl sw Tvr1
on/off
SET
SET
SET
SET
Tvr2
free free
