290 Programming examples - Using fl ight phases
Here, select the "Copy fl ight phase" menu item with
the selection keys then briefl y tap the center
SET key
of the right touch pad.
In the window which now appears, "Copy from
phase", "1 Normal" is selected …
7
Copy from phase:
3
5
=>
=>
2
4
6
1
8
normal
Thermal
Speed Launch
… and a subsequent brief tap on the center SET
key of the right touch pad will change the display to
"Copy to phase". Now the target is to be selected
(initially "2 Thermal") and confi rmed by another tap
on the center
SET key of the right touch pad. After
confi rmation of the subsequent safety query, all
settings are copied according to the selection.
Proceed in the same manner with the other two
phases ("1 Normal" to "3 Speed" and "1 Normal" to
"4 Start").
4
th
Step
Now three or four phases are programmed, the
settings are also copied and there is even a "soft"
transfer, but … there are still no fl ight-phase specifi c
settings.
Now, if applicable, in order to adapt the fl ap positions
to the different requirements of the individual fl ight
phases, in the menu …
»Control adjust« (page 108)
… the standard default "GL" is fi rst changed to "PH"
for "Phase" in the type column:
0%
+100%I5
I6
I7
I8
Typ
SEL
+100%
0.0 0.0
– travel + –time+
0%
+100%
+100%
0.0 0.0
0%
+100%
+100%
0.0 0.0
0%
+100%
+100%
0.0 0.0
GL
GL
GL
fr ---
fr
fr
fr
---
---
---
offset
PH
Normal
Then switch to the "Offset" column and make the
settings deviating from the "Normal" fl ight phase for the
ailerons. However, switch to the desired fl ight phase
beforehand, whose name is shown at the bottom in
the display, appropriate to the switch position. Both
positive and negative throw changes are possible.
These settings are to be made separately for each
ight phase:
+100%I5
I6
I7
I8
Typ
SEL
+100%
0.0 0.0
– travel + –time+
0%
+100%
+100%
0.0 0.0
0%
+100%
+100%
0.0 0.0
0%
+100%
+100%
0.0 0.0
GL
GL
GL
fr ---
fr
fr
fr
---
---
---
offset
PH
Thermal
–7%
5
th
Step
Any necessary phase-specifi c trimming of the
elevator is made with the help of the digital trimming
of the elevator joystick. This requires that you have
at least set the elevator trimming to "Phase" in the
»Stick mode« menu as already shown in this
programming example.
Alternatively, these settings can also be made in the
»Phase trim« menu …
¿
Normal
0%
EL
Thermal
0%
0%
0%
AI WK WK2
Thermal
Speed
Launch
0%
0%
0%
0%
0%
0%
0%
0%
0%
0%
0%
0%
QR2
0%
0%
0%
0%
6
th
Step
In the menu …
»Wing mixers« (beginning page 160)
… the fl ight phase name of the newly activated fl ight
phase appears at the bottom edge of the display. If
the switch position is now changed, the name of the
ight phase selected with the switch appears, but
with the previously copied settings of the fl ight phase
"Normal". Here you set you values phase-specifi cally
for the aileron differentiation, the share of the mixture
of transverse to side, and if applicable, also a mixture
of altitude to transverse. (The latter increases the
agility over the transverse axis when "Turning".)
Aileron differential
Brake settings
+33%
Aileron
+55%
WING MIXERS
Elevator
aileron
0%0%
–––
–––
rudder
2
3
4
5
Normal
Note:
The list of displayed options depends on the number
of servos entered in the "Ailerons/fl aps" line in the
»Model type« menu.
Now switch to the sub-menu …
