3. PIT.CRV

This function supports adjustment of the pitch curve driven by the throttle stick position for each

Q.LINK condition

Since pitch curve is closely related with Q.LINK setup, Q.LINK setup should precede PIT.CRV

setup.

Access Q.LINK setup page and check Q.LINK setup is completed correctly and touch “BACK” icon

to return FUNCTION page. (Refer to the manual on Q.LINK setup)

In FUNCTION page, touch “PIT.CRV” icon to call PIT.CRV setup page. You need to mark the

point on graph rst and then adjust the operation curve with “DEC”, “INC”, X-axis and Y-axis

buttons. Touch “ST OFF” to change to “ST ON” then the throttle position line appears on

graph. Move throttle stick and place the line at the desired position between point “L” and “H”

then touch “ENT” icon on the bottom right. Now the new point is marked in graph. You can

mark ve points between point “L” and “H” in the same way. Touch ST ON” to change to “ST

OFF” and complete the point setup. Now touch “DEC” or “INC” button to select point and touch

X-axis or Y-axis to activate and then touch DEC” or “INC” button to adjust the operation curve.

Turn on the preset Q.LINK switch then you may adjust the operation curve of every Q.LINK as

well.
