Telemetry
Telemetry
Telemetry
Telemetry
4. THR,CRV
This function supports adjustment of the throttle curve driven by the throttle stick position for
each Q.LINK condition
Since the throttle curve is closely related with Q.LINK setup, Q.LINK setup should precede
THR.CRV setup.
Access Q.LINK setup page and check Q.LINK setup is completed correctly and touch “BACK”
icon to return FUNCTION page. (Refer to the manual on Q.LINK setup)
In FUNCTION page, touch “THR.CRV” icon to call THR.CRV setup page. You need to mark
the point on graph rst and then adjust the operation curve with “DEC”, “INC”, X-axis and
Y-axis buttons. Touch “ST OFF” to switch to “ST ON” then the throttle position line appears
on graph. Move throttle stick and place the line at the desired position between point “L” and
“H” then touch “ENT” icon on the bottom right. Now the new point is marked in graph. You can
mark ve points between point “L” and “H” in the same way. Touch ST ON” to switch to “ST
OFF” and complete the point setup. Now touch “DEC” or “INC” button to select point and touch
X-axis or Y-axis to activate and then touch DEC” or “INC” button to adjust the operation curve.
Turn on the preset Q.LINK switch then you may adjust the operation curve for every Q.LINK as
well. When the setting is completed, touch “BACK” icon to return to the function page.
Touch
Touch
Touch
Touch
Touch
Touch
Touch
79
