Replace the lubricant cartridge as follows:
Prerequisite: The lubrication system is switched off
1 Turn the cover by the union ring in the direction of the arrow and re-
move it
2 Turn the empty lubricant cartridge in the direction of the arrow and re-
move it
3 Turn the cover lid of the new lubricant cartridge in the direction of the
arrow and remove it
4 Turn the new lubricant cartridge in the direction of the arrow by 2 full
rotations
(Label of the lubricant cartridge has to be aligned with the front of the lu-
brication system.)
5 Insert the union ring of the cover into the housing and turn tight in direc-
tion of the arrow
6 Check the lubrication system Ü283
The lubricant cartridge has been replaced.
