GETTING STARTED
19
The Function keys are used to enter and configure
different functions on the GDS-2000A.
Configures and runs automatic
measurements.
Configures and runs cursor
measurements.
Configures and runs GW Instek
applications.
Configures the acquisition mode,
including Segmented Memory
acquisition.
Configures the display settings.
Used to save and recall
waveforms, images, panel settings.
Configures the Hardcopy key,
display time, language, calibration
and Demo outputs. It also
accesses the file utilities menu.
Press the Autoset key to
automatically set the trigger,
horizontal scale and vertical scale.
Press to Freeze (Stop) or continue
(Run) signal acquisition (page 68).
The run stop key is also used to
run or stop Segmented Memory
acquisition (page 114).
