Appendix
User’s Manual 63
1. Channel information and Volt/Div
2. Time/DIV: lead the setting of the time base parameters
Select the time setting for the beam to sweep one major division on the screen..
3. Trigger State
4. Function menu
RUN: Run the application. Tap RUN menu again to stop it.
5. AUTO
Automatically set the oscilloscope controls to generate a usable display of the input signals.
6. Menu
7. Trigger position
Tap the trigger level icon and move up or move down, the trigger level value will display
on the screen.
8. CH2 Zero level
The marker shows the reference points of the displayed waveforms of CH1.
A signal is triggerred.
A signal is not triggerred.
