Appendix
User’s Manual 68
Appendix A: Specifications
Specifications Table:
Acquisition
Channels
2
Bandwidth
70 MHz analog bandwidth
Sample rate
250MSa/s(Single channel), 125MSa/s(Dual channel)
Mode
Normal, Peak Detect, Average(PC Software)
Input
Input Coupling
AC, DC,GND
Input Impedance
1MΩ, 25pF
Probe Attenuation Factors
1X, 10X, 100X, 1000X
Max. Input Voltage
35Vpk (DC + peak AC < 10 kHz, without external attenuation)
Horizontal
Scanning Speed
Range(Sec/div)
5ns/div ~ 500s/div(1-2-5 sequence)
Delay Time Accuracy
±50ppm(any interval 1ms)
Waveform Interpolation
Step, Linear, Sin(x)/x
Memory Depth
Max. 6K
Vertical
Vertical resolution
8 bits/channel
Gain range
10mV ~5V/div @ x1 probe(1,2,5 sequence)
100mV ~ 50V/div @ x10 probe
1V ~ 500V/div @ x100 probe
10V ~ 5KV/div @ x1000 probe
Position Range
±4 division
BandWidth
20MHz
Lower Frequency
Response(-3dB)
10Hz(at input BNC)
Rise Time at BNC
5ns
DC accuracy
±3%
Math
Addition, Subtraction, Multiplication, Division
FFT
Rectangular, Hanning, Hamming, Blackman Window
Trigger
Trigger Type
Edge trigger
Trigger Mode
Auto, Normal and Single
Source
CH1, CH2, EXT
