Mathematical operations
EN
Tablet1000 User manual Copyright © Qingdao Hantek Electronics Co., LTD
34
single pulse events, the "Acquisition mode" of oscilloscope can be set to "Average"
mode.
Use cursor to measure FFT waveform
To perform cursor measurement, tap the vertical or horizontal cursor at the bottom of the
interface. Use the AX and BX cursors to measure the frequency and the difference
between the two frequencies (BX-AX). Use the AY and BY cursors to measure the
amplitude and amplitude difference (BY-AY). For details, see the Cursor measurement
section.
