Tablet1000 User manual Copyright © Qingdao Hantek Electronics Co., LTD
66
The connection method suggested when measuring different gears.
16.1 Measurement
1. Dc and AC voltage measurement
⚫ Click [DMM] on the main interface to enter the multimeter interface.
⚫ Select DC volt (V-), DC millivolt (mV-), AC volt (V ~).
⚫ Insert the black probe into the COM banana jack input terminal, the red probe into
the V/Ω/C banana jack input terminal.
⚫ Connect the red and black probes to the measured point. The voltage value of the
measured point will be displayed.
2. DC and AC current measurement
⚫ Click [DMM] on the main interface to enter the multimeter interface.
⚫ To measure the DC current greater than 200mA, select DC ampere (A-) and AC
ampere (A ~), insert the black probe into the COM banana jack input terminal, the
red probe into the banana jack input terminal.
⚫ To measure the DC current less than 200mA, select DC milliampere (mA-) and AC
milliampere (mA ~), insert the black probe into the COM banana jack input terminal,
and the red probe into the mA banana jack input terminal.
⚫ Connect the red and black probes to the measured point. The voltage value of the
measured point will be displayed.
3. Resistance measurement
⚫ Click [DMM] on the main interface to enter the multimeter interface.
⚫ Select resistance (Ω);
⚫ Insert the black probe into the COM banana jack input terminal, the red probe into
the V/Ω/C banana jack input terminal.
⚫ Connect the red and black probes to the measured point. The voltage value of the
measured point will be displayed.
4. Capacitance measurement
⚫ Click [DMM] on the main interface to enter the multimeter interface.
⚫ Select capacitance ( );
⚫ Insert the black probe into the COM banana jack input terminal, the red probe into
the V/Ω/C banana jack input terminal.
⚫ Connect the red and black probes to the measured point. The voltage value of the
measured point will be displayed.
5. Diode measurement
⚫ Click [DMM] on the main interface to enter the multimeter interface.
⚫ Selective diode ( ).
