Reference channel
EN
Tablet1000 User manual Copyright © Qingdao Hantek Electronics Co., LTD
36
Figure 8.1 Reference waveform
Reference waveform movement and time base adjustment
Horizontal and vertical movement and scaling of the reference waveform are
independent of each channel.
The method of adjusting the horizontal or vertical position of the reference waveform is
the same as adjusting the channel. For details, refer to Set the horizontal system and Set
the vertical system.
