Mechanical installation
36 A0608-14.0 HBM: public T10F
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Centering point for
aligning the rotor
Marking
Sensor head
Fig. 6.10 Alignment marks on rotor and stator
