214 Fixed Cycles: Contour Pocket, Contour Trains
7.12 Programming Examples
8 CYCL DEF 21 PILOT DRILLING Cycle definition: Pilot drilling
Q10=5 ;PLUNGING DEPTH
Q11=250 ;FEED RATE FOR PLNGNG
Q13=2 ;ROUGH-OUT TOOL
9 CYCL CALL M3 Cycle call: Pilot drilling
10 L +250 R0 FMAX M6 Tool change
11 TOOL CALL 2 Z S3000 Call the tool for roughing/finishing, diameter 12
12 CYCL DEF 22 ROUGH-OUT Cycle definition: Rough-out
Q10=5 ;PLUNGING DEPTH
Q11=100 ;FEED RATE FOR PLNGNG
Q12=350 ;FEED RATE FOR ROUGHING
Q18=0 ;COARSE ROUGHING TOOL
Q19=150 ;RECIPROCATION FEED RATE
Q208=30000 ;RETRACTION FEED RATE
Q401=100 ;FEED RATE FACTOR
Q404=0 ;FINE ROUGH STRATEGY
13 CYCL CALL M3 Cycle call: Rough-out
14 CYCL DEF 23 FLOOR FINISHING Cycle definition: Floor finishing
Q11=100 ;FEED RATE FOR PLNGNG
Q12=200 ;FEED RATE FOR ROUGHING
Q208=30000 ;RETRACTION FEED RATE
15 CYCL CALL Cycle call: Floor finishing
16 CYCLE DEF 24 SIDE FINISHING Cycle definition: Side finishing
Q9=+1 ;DIRECTION
Q10=5 ;PLUNGING DEPTH
Q11=100 ;FEED RATE FOR PLNGNG
Q12=400 ;FEED RATE FOR ROUGHING
Q14=+0 ;ALLOWANCE FOR SIDE
17 CYCL CALL Cycle call: Side finishing
18 L Z+250 R0 FMAX M2 Retract in the tool axis, end program
