390 Touch Probe Cycles: Automatic Datum Setting
15.13 DATUM IN ONE AXIS (Cycle 419, DIN/ISO: G419)
Example: Datum setting in center of a circular segment and on top surface of
workpiece
0 BEGIN PGM CYC413 MM
1 TOOL CALL 69 Z Call tool 0 to define the touch probe axis
X
Y
25
25
Z
Y
25
30
