HEIDENHAIN iTNC 530 391
15.13 DATUM IN ONE AXIS (Cycle 419, DIN/ISO: G419)
2 TCH PROBE 413 DATUM OUTSIDE CIRCLE
Q321=+25 ;CENTER IN 1ST AXIS Center of circle: X coordinate
Q322=+25 ;CENTER IN 2ND AXIS Center of circle: Y coordinate
Q262=30 ;NOMINAL DIAMETER Circle diameter
Q325=+90 ;STARTING ANGLE Polar coordinate angle for 1st touch point
Q247=+45 ;STEPPING ANGLE Stepping angle for calculating the starting points 2 to 4
Q261=-5 ;MEASURING HEIGHT Coordinate in the touch probe axis in which the measurement is
made
Q320=2 ;SETUP CLEARANCE Safety clearance in addition to MP6140
Q260=+10 ;CLEARANCE HEIGHT Height in the touch probe axis at which the probe can traverse
without collision
Q301=0 ;MOVE TO CLEARANCE Do not move to clearance height between measuring points
Q305=0 ;NO. IN TABLE Set display
Q331=+0 ;DATUM Set the display in X to 0
Q332=+10 ;DATUM Set the display in Y to 10
Q303=+0 ;MEAS. VALUE TRANSFER Without function, since display is to be set
Q381=1 ;PROBE IN TS AXIS Also set datum in the touch probe axis
Q382=+25 ;1ST CO. FOR TS AXIS X coordinate of touch point
Q383=+25 ;2ND CO. FOR TS AXIS Y coordinate of touch point
Q384=+25 ;3RD CO. FOR TS AXIS Z coordinate of touch point
Q333=+0 ;DATUM Set the display in Z to 0
Q423=4 ;NO. OF MEAS. POINTS Number of measuring points
Q365=1 ;TYPE OF TRAVERSE Position on circular arc or linearly to the next touch point
3 CALL PGM 35K47 Part program call
4 END PGM CYC413 MM
