HEIDENHAIN iTNC 530 393
15.13 DATUM IN ONE AXIS (Cycle 419, DIN/ISO: G419)
3 TCH PROBE 416 DATUM CIRCLE CENTER
Q273=+35 ;CENTER IN 1ST AXIS Center of the bolt hole circle: X coordinate
Q274=+35 ;CENTER IN 2ND AXIS Center of the bolt hole circle: Y coordinate
Q262=50 ;NOMINAL DIAMETER Diameter of the bolt hole circle
Q291=+90 ;ANGLE OF 1ST HOLE Polar coordinate angle for 1st hole center 1
Q292=+180 ;ANGLE OF 2ND HOLE Polar coordinate angle for 2nd hole center 2
Q293=+270 ;ANGLE OF 3RD HOLE Polar coordinate angle for 3rd hole center 3
Q261=+15 ;MEASURING HEIGHT Coordinate in the touch probe axis in which the measurement is
made
Q260=+10 ;CLEARANCE HEIGHT Height in the touch probe axis at which the probe can traverse
without collision
Q305=1 ;NO. IN TABLE Enter center of bolt hole circle (X and Y) in line 1
Q331=+0 ;DATUM
Q332=+0 ;DATUM
Q303=+1 ;MEAS. VALUE TRANSFER In the preset table PRESET.PR, save the calculated datum
referenced to the machine-based coordinate system (REF system)
Q381=0 ;PROBE IN TS AXIS Do not set a datum in the touch probe axis
Q382=+0 ;1ST CO. FOR TS AXIS No function
Q383=+0 ;2ND CO. FOR TS AXIS No function
Q384=+0 ;3RD CO. FOR TS AXIS No function
Q333=+0 ;DATUM No function
Q320=0 ;SETUP CLEARANCE Safety clearance in addition to MP6140
4 CYCL DEF 247 DATUM SETTING Activate new preset with Cycle 247
Q339=1 ;DATUM NUMBER
6 CALL PGM 35KLZ Part program call
7 END PGM CYC416 MM
