442 Touch Probe Cycles: Automatic Workpiece Inspection
16.14 Programming Examples
Q285=0 ;MIN. LIMIT 1ST SIDE
Q286=0 ;MAX. LIMIT 2ND SIDE
Q287=0 ;MIN. LIMIT 2ND SIDE
Q279=0 ;TOLERANCE 1ST CENTER
Q280=0 ;TOLERANCE 2ND CENTER
Q281=0 ;MEASURING LOG
No measuring log transmission
Q309=0 ;PGM STOP IF ERROR
Do not output an error message
Q330=0 ;TOOL NUMBER
No tool monitoring
9 FN 2: Q1 = +Q1 - +Q164
Calculate length in X including the measured deviation
10 FN 2: Q2 = +Q2 - +Q165
Calculate length in Y including the measured deviation
11 L Z+100 R0 FMAX
Retract the touch probe, change the tool
12 TOOL CALL 1 Z S5000
Tool call for finishing
13 CALL LBL 1
Call subprogram for machining
14 L Z+100 R0 FMAX M2
Retract in the tool axis, end program
15 LBL 1
Subprogram with fixed cycle for rectangular studs
16 CYCL DEF 213 STUD FINISHING
Q200=20 ;SET-UP CLEARANCE
Q201=-10 ;DEPTH
Q206=150 ;FEED RATE FOR PLUNGING
Q202=5 ;PLUNGING DEPTH
Q207=500 ;FEED RATE FOR MILLING
Q203=+10 ;SURFACE COORDINATE
Q204=20 ;2ND SET-UP CLEARANCE
Q216=+50 ;CENTER IN 1ST AXIS
Q217=+50 ;CENTER IN 2ND AXIS
Q218=Q1 ;FIRST SIDE LENGTH
Length in X variable for roughing and finishing
Q219=Q2 ;2ND SIDE LENGTH
Length in Y variable for roughing and finishing
Q220=0 ;CORNER RADIUS
Q221=0 ;ALLOWANCE IN 1ST AXS
17 CYCL CALL M3
Cycle call
18 LBL 0
End of subprogram
19 END PGM BEAMS MM
