HEIDENHAIN ITNC 530 - CYCLE PROGRAMMING User Manual

444 Touch Probe Cycles: Automatic Workpiece Inspection
16.14 Programming Examples
Q284=90.15;MAX. LIMIT 1ST SIDE Maximum limit in X
Q285=89.95;MIN. LIMIT 1ST SIDE Minimum limit in X
Q286=70.1 ;MAX. LIMIT 2ND SIDE Maximum limit in Y
Q287=69.9 ;MIN. LIMIT 2ND SIDE Minimum limit in Y
Q279=0.15 ;TOLERANCE 1ST CENTER Permissible position deviation in X
Q280=0.1 ;TOLERANCE 2ND CENTER Permissible position deviation in Y
Q281=1 ;MEASURING LOG Save measuring log to a file
Q309=0 ;PGM STOP IF ERROR Do not display an error message in case of a tolerance violation
Q330=0 ;TOOL NUMBER No tool monitoring
4 L Z+100 R0 FMAX M2 Retract in the tool axis, end program
5 END PGM BSMEAS MM
