490 Touch Probe Cycles: Automatic Kinematics Measurement
18.5 PRESET COMPENSATION (Cycle 452, DIN/ISO: G452, Option)
U Measure the drift of the axes at regular intervals.
U Insert the touch probe.
U Activate the preset in the calibration sphere.
U Use Cycle 452 to measure the kinematics.
U The preset and the position of the calibration sphere must not be
changed during the complete process.
Example: Drift compensation
4 TOOL CALL “TASTER“ Z
5 TCH PROBE 452 PRESET COMPENSATION
Q407=12.5 ;SPHERE RADIUS
Q320=0 ;SET-UP CLEARANCE
Q408=0 ;RETR. HEIGHT
Q253=99999;F PRE-POSITIONING
Q380=45 ;REFERENCE ANGLE
Q411=-90 ;START ANGLE A AXIS
Q412=+90 ;END ANGLE A AXIS
Q413=45 ;INCID. ANGLE A AXIS
Q414=4 ;MEAS. POINTS A AXIS
Q415=-90 ;START ANGLE B AXIS
Q416=+90 ;END ANGLE B AXIS
Q417=0 ;INCID. ANGLE B AXIS
Q418=2 ;MEAS. POINTS B AXIS
Q419=+90 ;START ANGLE C AXIS
Q420=+270 ;END ANGLE C AXIS
Q421=0 ;INCID. ANGLE C AXIS
Q422=3 ;MEAS. POINTS C AXIS
Q423=3 ;NO. OF MEAS. POINTS
Q432=0 ;BACKLASH, ANG. RANGE
This procedure can also be performed on machines
without rotary axes.
