HEIDENHAIN iTNC 530 491
18.5 PRESET COMPENSATION (Cycle 452, DIN/ISO: G452, Option)
Log function
After running Cycle 452, the TNC creates a measuring log
(TCHPR452.TXT) containing the following information:
 Creation date and time of the log
 Path of the NC program from which the cycle was run
 Active kinematic number
 Entered calibration sphere radius
 For each measured rotary axis:
 Starting angle
 End angle
 Angle of incidence
 Number of measuring points
 Dispersion (standard deviation)
 Maximum error
 Angular error
 Ascertained backlash
 Averaged positioning error
 Measuring circle radius
 Compensation values in all axes (preset shift)
 Evaluation of measuring points
 Measurement uncertainty of rotary axes
Notes on log data
(see “Notes on log data” on page 480)
