HEIDENHAIN iTNC 530 511
Overview
Touch probe cycles
Cycle
number
Cycle designation
DEF
active
CALL
active
Page
0 Reference plane îš„ Page 402
1 Polar datum îš„ Page 403
2 Calibrate TS radius îš„ Page 447
3Measuring îš„ Page 449
4 Measuring in 3-D îš„ Page 451
9 Calibrate TS length îš„ Page 448
30 Calibrating the TT îš„ Page 499
31 Measure/Inspect the tool length îš„ Page 501
32 Measure/Inspect the tool radius îš„ Page 503
33 Measure/Inspect the tool length and the tool radius îš„ Page 505
400 Basic rotation using two points îš„ Page 322
401 Basic rotation from two holes îš„ Page 325
402 Basic rotation from two studs îš„ Page 328
403 Compensate misalignment with rotary axis îš„ Page 331
404 Set basic rotation îš„ Page 335
405 Compensate misalignment with the C axis îš„ Page 336
408 Reference point at slot center (FCL 3 function) îš„ Page 345
409 Reference point at ridge center (FCL 3 function) îš„ Page 349
410 Datum from inside of rectangle îš„ Page 352
411 Datum from outside of rectangle îš„ Page 356
412 Datum from inside of circle (hole) îš„ Page 360
413 Datum from outside of circle (stud) îš„ Page 364
414 Datum from outside of corner îš„ Page 368
415 Datum from inside of corner îš„ Page 373
416 Datum from circle center îš„ Page 377
417 Datum in touch probe axis îš„ Page 381
418 Datum at center between four holes îš„ Page 383
419 Datum in any one axis îš„ Page 387
