Overview
420 Workpiece—measure angle  Page 405
421 Workpiece—measure hole (center and diameter of hole)  Page 408
422 Workpiece—measure circle from outside (diameter of circular stud)  Page 412
423 Workpiece—measure rectangle from inside  Page 416
424 Workpiece—measure rectangle from outside  Page 420
425 Workpiece—measure inside width (slot)  Page 424
426 Workpiece—measure outside width (ridge)  Page 427
427 Workpiece—measure in any selectable axis  Page 430
430 Workpiece—measure bolt hole circle  Page 433
431 Workpiece—measure plane  Page 433
440 Measure axis shift îš„ Page 453
441 Rapid probing: Set global touch probe parameters (FCL 2 function) îš„ Page 456
450 KinematicsOpt: Save kinematics (option) îš„ Page 464
451 KinematicsOpt: Measure kinematics (option) îš„ Page 466
452 KinematicsOpt: Preset compensation (option) îš„ Page 466
460 Calibrate TS: Radius and length calibration on a calibration sphere îš„ Page 458
480 Calibrate the TT îš„ Page 499
481 Measure/Inspect the tool length îš„ Page 501
482 Measure/Inspect the tool radius îš„ Page 503
483 Measure/Inspect the tool length and the tool radius îš„ Page 505
484 Calibrate infrared TT îš„ Page 500
Cycle
number
Cycle designation
DEF
active
CALL
active
Page
