Heyer Modular+ - Connectors on Module 1

Repair Information
22
2.10.1 Connectors on module 1
Connector connected to Plug conf. Func. / Signal
X4 Module 2 10 pole communication
with module 2
Connector connected to Plug conf. Func. / Signal
X5 EL Display 20 pole Connected to the
display
Connector connected to Plug conf. Func. / Signal
X6 Power supply 4 pole Power suppy
Connector connected to Plug conf. Func. / Signal
X7 Touch screen 32 pole communication
with touch screen
Connector connected to Plug conf. Func. / Signal
X8 Module 2 14 pole communication
with module 2
Connector connected to Plug conf. Func. / Signal
X9 Module 2 28 pole communication
with module 2
Connector connected to Plug conf. Func. / Signal
X10 Selector switch 14 pole communication
With the selector
switch
Connector connected to Plug conf. Func. / Signal
X19 LCD Display Flat cable
connector
Connected to the
display
Connector connected to Plug conf. Func. / Signal
X20
(on the
backside)
Display
illumination
4 pole Power supply
display
illumination
